Electric Hydraulic Articulated/Telescopic Boom Lift, High Quality Curved/Straight Arm Lifting Platform

1 / 5

Electric Hydraulic Articulated/Telescopic Boom Lift, High Quality Curved/Straight Arm Lifting Platform

Customization:	Available
Lift Mechanism:	Telescoping Lift
Carrying Capacity:	Special Weight Level

Send Inquiry

Product Description

Technical Specifications Overview

Model No.SH16RE / SH22RE

Driven TypeAC (Battery Powered)

FeatureExplosion-Proof

CertificationGS, CE

Max Working Height17.7m - 22.5m

Max Travel Speed5.2km/H

OriginShandong, China

Running ModeMoving

Key Features & Performance

SH16RE Series

Compact Design: 1.9m narrow body with only 50mm tail sweep, perfect for confined indoor spaces.
Eco-Friendly Operation: Pure battery power ensures zero emissions and silent running for indoor use.
Precision Control: Dual proportional joysticks allow for smooth luffing, telescoping, and rotation.
Intelligent Diagnosis: Smart display screen for real-time status monitoring and easy fault diagnosis.
High Stability: Supports an allowable inclination angle of up to 5 degrees.

SH22RE Series

Terrain Adaptability: Full-time floating feature provides excellent off-road performance.
Efficient Control: Load-sensing system ensures stable, rapid, and energy-saving movements.
Cost-Effective Maintenance: Non-telescoping wire rope system reduces long-term maintenance costs.
High ROI: Low initial investment and operating costs lead to superior returns.

Detailed Parameter Comparison

Specifications	SH16RE	SH22RE
Maximum working height	17.7m	22.5m
Maximum platform height	15.7m	13.3m
Maximum horizontal extension	9.3m	12.7m
Overall width (stowed)	1.9m	2.49m
Platform size	1.450.851.1m	2.440.911.1m
Rotary table rotation	355°	360°
Gradeability	30%	35%
Battery specification	8*6V/420Ah	48V, 480Ah/528Ah
Overall machine weight	7300kg	12260kg

Product Display

Frequently Asked Questions

What is the main difference between SH16RE and SH22RE?

The SH16RE is designed for narrow spaces (1.9m width) with a working height of 17.7m, while the SH22RE offers a higher working height of 22.5m and enhanced off-road performance.

Can these platforms be used for indoor construction?

Yes, especially the SH16RE. It is purely battery-powered, ensuring zero emissions and silent operation, making it ideal for indoor environments.

Are these lifts easy to maintain?

Absolutely. They feature intelligent display screens for easy fault diagnosis and non-telescoping wire rope systems that significantly reduce maintenance costs.

What is the gradeability of these machines?

The SH16RE has a gradeability of 30%, while the SH22RE is even stronger at 35%, allowing them to handle inclined surfaces effectively.

How precise are the controls?

The machines are equipped with proportional joysticks that provide gradual and smooth control over boom movements and travel speed, allowing for precise positioning.

What certifications do these products have?

All models are certified with GS and CE standards, ensuring they meet international safety and quality requirements.
